TRANSMISSION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

3-M29

(Continued)

Signals are sent from the Hi-Lo change lever switch to the ECU. Then the signals are sent from the ECU to the

Hi-Lo change valve. Then the Hi-Lo solenoid valve is opened. As a result, the position of the two-speed change spool

is changed with charge oil to the position shown in the drawing. In this state, oil between

"A"

 and

"C"

 (Forward and

high pressure side) is guided through the two-speed change spool to the pistons on the Hi side, and the angle of the

swashplate on the motor side is changed as shown in the drawing (the inclination angle becomes smaller). As a result,

the revolving speed of the motor shaft is increased.

* When the angle of the swashplate on the motor side is changed, the swashplate on the pump side goes back

slightly toward the neutral position to achieve smooth shift transmission when speed is changed (from Lo to Hi). After

the angle of the swashplate on the motor side is changed, the swashplate on the pump side gradually returns to its

original position.

9Y1210824TRM0035US0

KiSC issued 03, 2016 A
