L3560,L4060,L4760,L5060,L5460,L6060
9 ELECTRICAL SYSTEM
background image

ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S3

GAUGES

ELECTRONIC INSTRUMENT PANEL (INTELLIPANEL)

9Y1210824ELS0150US0

Symptom

Probable Cause

Solution

Reference

Page

Fuel Gauge Does Not
Function

Fuel level sensor damaged

Replace

9-S74

Wiring harness disconnected or improperly

connected

Repair or replace

Electrical instrument panel damaged

Replace

9-S15

Coolant Temperature
Gauge Does Not
Function

Coolant temperature sensor damaged

Replace

9-S74

Wiring harness disconnected or improperly

connected

Repair or replace

Electrical instrument panel damaged

Replace

9-S15

Symptom

Probable Cause

Solution

Reference

Page

Nothing is Displayed
in LCD

Battery discharged or damaged (Battery voltage

is below 7 V)

Recharge or replace

9-S12

Slow blow fuse blown

Replace

9-S34

Electronic instrument panel connector disconnect Connect

9-S37

Electronic instrument panel damaged

Replace

9-S15

Indication on LCD
Does Not Change
When Pushing the
Display Mode Switch

Display mode switch damaged

Replace

9-S38

Wiring harness disconnected

Repair

Traveling Speed is
Not Indicating

Wiring harness disconnected

Repair

Traveling speed sensor damaged

Replace

9-S49,

9-S53,

9-S60

PTO Speed in Not
Indicating

Wiring harness disconnected

Repair

Fuel Gauge is
Indicating Always E

Wiring harness (GND) disconnected

Repair or replace

Fuel unit damaged

Replace

9-S74

Fuel Gauge is
Indicating Always F

Wiring harness short-circuited

Repair or replace

Fuel unit damaged

Replace

9-S74

Position of Range
Gear Shift Lever Is
Not Indicated
(For HST)

Wiring harness disconnected

Repair or replace

Range gear shift lever sensor damaged

Replace

9-S54

Mode setting incorrect

Reset Mode N → K →

L

9-S27,

9-S29,

9-S30

KiSC issued 03, 2016 A
