TRANSMISSION

L3560, L4060, L4760, L5060, L5460, L6060, WSM

3-S28

(Continued)

NOTE

• When "Out of Setting Position ERROR No. ** (72 or 73)" is

displayed (l), refer to the below chart.

12.

"Hold button for 3s more"

  is  displayed

(f)

  :  Hold  down  the

display mode switch (2) for more than 3 seconds.

13.

"Step-03"

 is displayed

(g)

 : Follow the procedure as follow.

Keep the HST pedal at the

"Full reverse"

 position.

14. Wait  until

"Step-04"

  is  displayed.  Then  proceed  to  the  next

step.

NOTE

• When ''Out of Setting Position ERROR No.** (72 or 73)'' is

displayed, refers to the below

15.

"Hold button for 3s more"

  is  displayed

(i)

  :  Hold  down  the

display mode switch (2) for more than 3 seconds.

16.

"Complete"

 is displayed

(j)

 : The setting has been preserved

correctly to the main ECU.

17. If

"Not Complete"

 is displayed, repeat the procedure.

18. Turn off the main switch.

IMPORTANT

• After setting the mode "N", reset the mode "K" and "L".The

tractor does not move normally without resetting mode "K"
and "L". (HST only)

9Y1210824TRS0187US0

Error Display

Fine-adjustment

ERROR No.71

Range Gear Shift Lever Sensor

ERROR No.72

HST Pedal Sensor

ERROR No.73

Swashplate Position Sensor

ERROR No.75

Throttle Sensor

(a) Mode Selection Display
(b) Information Display
(c) Setting Display-1
(d) Adjusting Display-1
(e) Setting Display-2
(f)

Adjusting Display-2

(g) Setting Display-3

(h) Setting Display-4
(i)

Adjusting Display-3

(j)

Correct Preserving Display

(k) Error Display-1
(l)

Error Display-2

(m) Error Display-3

KiSC issued 03, 2016 A
